| مكان المنشأ: | شنتشن ، الصين |
|---|---|
| اسم العلامة التجارية: | RAYMO |
| إصدار الشهادات: | CE ROHS2.0 ISO9001 REACH |
| Model Number: | PFG.1B.302.CLLD52Z |
| الحد الأدنى لكمية: | 1 قطعة/قطعة |
| الأسعار: | negotiable |
| Packaging Details: | Plastic Bag & Carton |
| وقت التسليم: | 5-7 أيام عمل |
| Payment Terms: | T/T, D/A, D/P,L/C, MoneyGram, Western Union |
| القدرة على العرض: | 5000 قطعة / أسبوع |
| Prct Name: | Metal circular push pull connector | Model: | FGG cable mout plug , nut for a bend relief |
|---|---|---|---|
| حجم القشرة: | 1 ب | Contact no.: | 2pin male contact |
| Insulator: | PPS, PEEK | Shell Color: | Silver chrome black chrome |
| إبراز: | electronic cable connectors,cable connector plug,cable connector plug |
||
PFG.1B.302.CLLD52Z
Cable mount Socket, 1B series shell size, 2pin female contact, 52cable collet for OD4.2-5.2mm cable, nut for a bend relief, 1 key, 0 degree, brass shell with natural chrome plated
make with cable by overmoudling, like HMDI, DB9, D-SUB, RS232,
cable can be twisted wire depend on custom options
| Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shell Material | Brass with chrome plated | Humidity | up to 95% at 60° C/140F |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >144hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
| IP Rating | IP 68 | Endurance(shell) | 5000 mating cycles |
