| مكان المنشأ: | الصين |
|---|---|
| اسم العلامة التجارية: | RAYMO |
| إصدار الشهادات: | ISO:9001-2015 |
| Model Number: | ECG.0B.304.CLN |
| الحد الأدنى لكمية: | 1 قطعة/قطعة |
| الأسعار: | negotiable |
| Packaging Details: | Plastic Bag & Carton |
| وقت التسليم: | 5-7 أيام عمل |
| Payment Terms: | T/T, PAYPAL, EBAY |
| القدرة على العرض: | 5000 قطعة / أسبوع |
| Shell size: | 0B series | Contact no.: | 4pin female contact |
|---|---|---|---|
| Prct Name: | PCB Connector | عازل: | PPS |
| مادة الصدفة: | كوزن | صالة: | PCB |
| إبراز: | circuit board connectors,pcb board connector,pcb board connector |
||
| Connector Descitption Details: | |||
| Shell model | Straight plug FGG | Shell size | 00B 0B 1B 2B 3B 4B 5B |
| Gender | Male | Contact No. | 2,3,4,5,6,7,8,9,10,12,14,16,19,30,32, |
| MOQ | 1pc | Delivery | 2-5 working days |
| Endurance(shell) | 5000 mating cycles | Humidity | up to 95% at 60° C/140F |
| Technical Characteristics | |||
| Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shell Material | Brass with chrome plated | Humidity | up to 95% at 60° C/140F |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >144hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
| IP Rating | IP 50 | Endurance(shell) | 5000 mating cycles |
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
