| مكان المنشأ: | شنتشن ، الصين |
|---|---|
| اسم العلامة التجارية: | RAYMO |
| إصدار الشهادات: | CE, REACH, ISO:9001-2015, SGS, ROHS |
| Model Number: | ERA.1E.304.CLL |
| الحد الأدنى لكمية: | 1 قطعة/قطعة |
| الأسعار: | negotiable |
| Packaging Details: | Plastic Bag & Carton |
| وقت التسليم: | 5-7 أيام عمل |
| Payment Terms: | T/T, Western Union, D/A, D/P,L/C, MoneyGram |
| القدرة على العرض: | 5000 قطعة / أسبوع |
| Series: | Half Moon Connectors | Shell size: | 0E, 1E, 2E |
|---|---|---|---|
| Contact no.: | 2 to 19pins | Insulator: | PPS, PEEK |
| Application: | Weatherproof applications | ||
| إبراز: | cable elbow connector,cable to cable connector,cable to cable connector |
||
Half Moon Connectors E series,FFA ERA connectors for outdoor application ERA.1E.303.CLL
|
Temperature Range |
- 55° C, +200° C |
Resistance to vibrations |
10-2000 Hz, 15g |
|
Shell Material |
Brass with chrome plated |
Humidity |
up to 95% at 60° C |
|
Shock Resistance |
100 g, 6 ms |
Salt spray corrosion test |
>96hr |
|
Climatical Category |
50/175/21 |
Shielding (min) |
> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
|
IP Rating |
IP 68 |
Endurance(shell) |
≥5000 mating cycles |
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers.
This vast portfolio enables you to select the ideal connector configuration to suit almost any specific requirement in most markets inclyding medical devices, test and measurement instruments, machinery, audio video broadcast, telecommunications and military
The use of enviroment,indoor or ourdoors,waterproof or not
The panel hole size, to seclect the approproate plug and socket of right dimension
The current voltage and the realization of the function, to determin the cores seclect the appropriate clam diameter and sheath according to the actual needs of different angles of the keys, to determin the keying
100% compatible with lemo, , fischer connector
All the prcts we got CE, ROHS, SGS,ISO9000 certificate
Help you save at least 50% cost
Fast delivery: 2-15 working days
Cable assembly offer, help you save prction time
Except connectors,we do cable assemble for circular connectors too.
We can make all types of cables as per customers' request. Use any kind of connectors, like Hirose, Cannon, BNC, TNC, D-sub, USB, RJ45, Dtap, JST, Molex, and so on. Just tell us your need, leave the rest to RAYMO!
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
