Male Solder 6 Pin FGG 1B Circular Push Pull Connectors IP50

Male Solder 6 Pin FGG 1B Circular Push Pull Connectors IP50
Male Solder 6 Pin FGG 1B Circular Push Pull Connectors IP50 Male Solder 6 Pin FGG 1B Circular Push Pull Connectors IP50
المعلومات الأساسية
مكان المنشأ: شنتشن ، الصين
اسم العلامة التجارية: RAYMO
إصدار الشهادات: RoHS2.0, ISO:9001-2015, CE , SGS, REACH
رقم الموديل: FGG 0B 1B 2B
الحد الأدنى لكمية: 1piece
الأسعار: negotiable
تفاصيل التغليف: 100 قطعة / الشركة التونسية للملاحة
وقت التسليم: 5-7 أيام العمل
شروط الدفع: Western Union ، T/T ، D/P ، D/A ، L/C ، Moneygram
القدرة على العرض: 5000 قطعة في الأسبوع
ﺎﺘﺼﻟ ﺍﻶﻧ
اسم PRCT: دفع موصل سحب يكتب: FGG قابس
حجم القشرة: 0B 1B 2B رقم الاتصال.: 6 دبابيس
صالة: لحام تصنيف الملكية الفكرية: IP50
إبراز:

1B Circular Push Pull Connectors,FGG Circular Push Pull Connectors,IP50 6 Pin Circular Connector

,

FGG Circular Push Pull Connectors

,

IP50 6 Pin Circular Connector

 data signal transfer male solder push pull self locking cable plug, 6 pin circular connector

100% compatible with LEMO original FGG 0B 1B 2B 3B series



Prct description



FGG.0B.306.CLAD42 = RM-FGG-0BC-306-JS42 .Straight plug with key(G) and cable collet, 0B series, multipole 6 contacts, outer shell in natural chrome-plated brass, PPS insulator, male solder contacts, collet for 3.2-4.2mm diameter cable, round nut without bend relief, IP50.

RM-B series metal circular push pull connector with below features:

  • Secure high performance push-pull self-locking system
  • High pin density contributing to equipment miniaturization
  • Alignment Key and Polarized Keying System to avoid cross-interface
  • 360° EMC shielding
  • Robust and shock resistant designs
  • Functional in a wide temperature range from -50°C to +250°C
  • Available solder, PCB and right angle PCB contact



Technical Characteristics
Temperature Range
-55°C, +250°C
Resistance to vibrations
15 g [10 Hz - 2000 Hz]
Shock Resistance
100 g [ 6 ms]
Salt spray corrosion test
>96hrs
Climatical Category
50/175/21
Humidity
Up to 95% at 60°C
IP Rating
IP50
Certifications
ISO9001/ CE/ ROHS2.0/ SGS



Raymo company intrce



As a creative customer-oriented manufacturer located in Shenzhen, Raymo focusing on manufacturing connectors and cable assemblies to serve over 75 countries and regions since 2010.

We can offer to customer

  • Metal push pull connectors,
  • Electrical connector
  • Medical plastic connectors,
  • Camera connectors,
  • Waterproof/watertight connectors,
  • Quick release connectors
  • Cable assemblies.
  • OEM is accepted.
Applications
RAYMO connectors have been widely used in the areas of telecommunication, electronics, medical equipments, aviation, audio-video, petroleum, motor and power industries, electrical signal connection, IC control systems, test and measurement instruments, ect.

Male Solder 6 Pin FGG 1B Circular Push Pull Connectors IP50 0
