| مكان المنشأ: | شنتشن ، الصين |
|---|---|
| اسم العلامة التجارية: | RAYMO |
| إصدار الشهادات: | RoHS2.0, ISO:9001-2015, CE , SGS, REACH |
| رقم الموديل: | egj.1b.305.cla |
| الحد الأدنى لكمية: | 5 قطعة/قطع |
| الأسعار: | negotiable |
| تفاصيل التغليف: | كيس بلاستيكي وكرتون |
| وقت التسليم: | 5-7WDS |
| شروط الدفع: | Western Union ، L/C ، D/A ، D/P ، T/T |
| القدرة على العرض: | 5000 قطعة / أسبوع |
| يكتب: | موصلات سحب الدافع الدائري للطيران | حجم القشرة: | 1 ب (حجم قذيفة آخر متاح) |
|---|---|---|---|
| رقم الاتصال.: | 2.3.4.5.6.7.8.9.10.14.16 دبابيس | عازل: | PPS |
| تَحمُّل: | 5000 مرة دفع الضغط | مادة الاتصال: | سبيكة النحاس مطلية بالذهب |
| إبراز: | 1B Shell Electronics Component Connectors,SGS Circular Power Connector,SGS Cable Mount Connector,SGS Circular Power Connector,SGS Cable Mount Connector |
||
Double Slot 1B Shell Electronics Component Connectors 45 Degree
Aviation circular push pull connector, double slot FGJ EGJ 0B 1B 45 degree double key connector, EGJ.1B.305
|
Temperature Range |
- 40° C, +125° C |
Resistance to vibrations |
15 g [10 Hz - 2000 Hz] |
|
Shell Material |
Brass with chrome plated |
Humidity |
up to 95% at 60° C/140F |
|
Shock Resistance |
100 g [ 6 ms] |
Salt spray corrosion test |
>144hr |
|
Climatical Category |
50/175/21 |
Shielding (min) |
> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
|
IP Rating |
IP50 |
Endurance(shell) |
5000 mating cycles |
|
1
|
push-pull self-locking connector, 100% compatible with original LEMO connector
|
|
2
|
a variety of size optional(00B, 0B, 1B, 2B, 3B)
|
|
3
|
solder or crimp core; straight or 90 degree
|
|
4
|
meet the most industries (like medical equipment, test equipment, machinery, audio and video broadcasting, telecommunications and military, etc.) any one of the special application requirements
|
|
5
|
360 degree complete EMC shielding, shock resistance, vibration resistance and corrosion resistance
|
|
6
|
you can buy FGG or EGG connector separately, or both
|
Contacts And Model
|
LEMO Type
|
Raymo Type
|
Pins
|
| EGJ.1B.305.CLA |
RM-EGJ-1BC-.305-JS
|
8
|
|
0B
|
RM-0B
|
2 3 4 5 6 7 9
|
|
1B
|
RM-1B
|
2 3 4 5 6 7 8 10 12 14 16
|
|
2B
|
RM-2B
|
2 3 4 5 6 7 8 10 12 16 19 20 26
|
|
3B
|
RM-3B
|
3 4 6 8 9 10 12 14 16 18 21 226 30 32
|
| 4B | RM-4B |
7 10 24 |
RAYMO is a manufactuer that:
1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample :
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5. What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory
has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.
